Datalogic Lynx Instruction Manual

ADVANCED DATA FORMAT
2.14.4 Mismatch Result
The result of each format may be set in case the match conditions previously
selected are not satisfied.
Once the desired formats have been enabled and a code has been read, the results
corresponding to each format will be concatenated together and transmitted in the
output message. For this reason, it is strongly advised to set the mismatch result for
each format.
Example
Decoded Code: <DATALOGICproduct>
Format definition:
Format Enable/Disable Match Condition Function Mismatch Result
Format 1 Enabled Code having a length
of 16 characters
Select field from
position1 to
position3
No string
Format 2 Disabled / / /
Format 3 Enabled Code having a length
of 25 characters
Substitute string
"ab" with string
"12"
Unformatted read
code
Format 4 Enabled Code having the
substring "AT" in
position 2
Insert string
"789" in position
7
Unformatted read
code
Format 5 Enabled Code belonging to the
PDF417 symbology
Delete string
"DA" and "pr"
Unformatted read
code
Output message: <DATDATALOGICproductDATALO789GICproductDATALOGICproduct>
Format 1 Format 3 Format 4 Format 5
Define Mismatch Result
Mismatch Result
AOCLFLHODNGNENEIEPANHOGOCK
AHPNIJAMDKEOFMHMLJAKEFGEIK
AKCBPJCJGIIJCMCFHPJPBJONNK
AEFBJLBGMHPKMJGONHLFIIIHGK
AAPHBAJJCDBDNKDEDGEINLGHBK
AFLFAMLJPMLKOLLPNDLGCBAIIK
DLDLLDLDDLLLLLLDDDLDDLDLDL
Read the above code and:
1. read a number in the range 1-5 corresponding to the
desired format number;
2. 0 = empty string as output
1 = unformatted read code as output.
108
AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France
Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr

Datalogic Lynx Specifications

General

Display diagonal	2.7 \
Display resolution	320 x 240 pixels
Display number of colors	262144 colors
Flash memory	0.512 GB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	microSD (TransFlash), microSDHC
Processor family	PXA 310
Processor frequency	0.806 GHz
Data network	HSPA+
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	2.0+EDR
Operating frequency	800, 850, 900, 1900, 2100 MHz
Security algorithms	CCX v4
Built-in camera	-
Interface	micro USB, RS-232
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Battery capacity	1800 mAh
RFID reader	No
Product color	Black
Keyboard layout	QWERTY
Keypad number of keys	46
Operating system installed	Windows Embedded Handheld 6.5

Weight and Dimensions

Depth	27 mm
Width	68 mm
Height	144 mm
Weight	270 g
