Linear barcode 2D Matrix symbol
Figure 5 - Relative Size and Location of Aiming System Pattern
(mil size) should be read farther from the unit. (See
hapter 5 for further details).
.4.2 Normal Operation
ynx™ normally functions by capturing and decoding codes.
the aiming system keeps on showing the field of view on the
re reading code symbols, adjust the distance at which you are holding the
ader.
The field of view created by the aiming system will be smaller when the Lynx™ is
closer to the code and larger when it is farther from the code. Symbologies with
smaller bars or elements (mil size) should be read closer to the unit. Symbologies
with larger bars or elements
c
1
L
Point the reader at the target and pull the trigger partially to enable the aiming
system. Then, pull it completely to capture and decode the image. The reader will
repeatedly flash until the symbol is decoded or timeout is reached. In between the
flashes of the reader,
target (see Figure 5
).
As you a
re
The LYNX™ hand-held reader aiming system is designed for general
reading and decoding of 1D and 2D symbols. Some variation in
NOTE
reading distance will occur due to narrow bar width and other factors.
6
