Datalogic Lynx Instruction Manual

GETTING STARTED
1
1 GETTING STARTED
1.1 DESCRIPTION
The LYNX™ Hand-Held Reader packs a lot of performance into an attractive, rugged,
hand-held device. It operates in commercial and industrial environments as well as
the front office.
Omnidirectional
Operating
To read a symbol or capture an image, you simply aim the
reader and pull the trigger. Since the orientation of the symbol
is not important, the LYNX™ reader is a powerful,
omnidirectional device.
Decoding
And
Imaging
Thanks to powerful algorithms, Lynx™ reliably decodes all major
1D (linear) barcodes, 2D stacked codes (such as PDF417), 2D
matrix symbols (such as DataMatrix), postal codes (such as
POSTNET, PLANET). The data stream — acquired from
decoding a symbol — is rapidly sent to the host. The reader is
immediately available to read another symbol.
Lynx™ can also function as a camera by capturing images of
labels, signatures, and other items. (see par. 1.4.3 for further
details).
FLASH MEMORY
Flash technology allows to upgrade the LYNX™ reader as new
symbologies are supported or as improved decoding
algorithms become available.
1.2 PACKAGE CONTENTS
The following parts are included in the LYNX™ package contents:
• LYNX™ Hand-Held Reader
• CD-ROM containing the Lynx™ Configuration Tools software
• LYNX™ Instruction Manual
You may want to save your packing material in case you need to ship the reader at
some later time.
1
AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France
Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr

Datalogic Lynx Specifications

General

Display diagonal	2.7 \
Display resolution	320 x 240 pixels
Display number of colors	262144 colors
Flash memory	0.512 GB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	microSD (TransFlash), microSDHC
Processor family	PXA 310
Processor frequency	0.806 GHz
Data network	HSPA+
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	2.0+EDR
Operating frequency	800, 850, 900, 1900, 2100 MHz
Security algorithms	CCX v4
Built-in camera	-
Interface	micro USB, RS-232
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Battery capacity	1800 mAh
RFID reader	No
Product color	Black
Keyboard layout	QWERTY
Keypad number of keys	46
Operating system installed	Windows Embedded Handheld 6.5

Weight and Dimensions

Depth	27 mm
Width	68 mm
Height	144 mm
Weight	270 g
