LYNX™
5
LYNX™ D432E
Optical Features
Focus distance 65 mm
Field of view 20° (H) x 15° (V)
Horizontal field of view at
distance (
d) in mm
0.32
d + 8.67
Vertical field of view at
distance (
d) in mm
0.24
d + 6.50
Max Resolution
Linear codes - mm (mils) Datamatrix – mm (mils)
0.05 (2.0) 0.10 (4.0)
Depth of field*
1D (linear): X-dimension Symbol size
cm (in)
DOF
mm (mils) cm (in)
Code39 0.076 (3) 1.2 (0.47) 5.0 to 7.5
(1.96 to 2.95)
0.13 (5) 1.2 (0.47) 4.0 to 9.5
(1.57 to 3.74)
2D: X-dimension
mm (mils)
Symbol size DOF
cm (in) cm (in)
PDF417 0.76 (3) 0.65 x 0.55
(0.26 x 0.22)
5.0 to 8.0
(1.96 to 3.15)
0.25 (10) 2.2 x 1.8
(0.86 x 0.71)
4.0 to 13.3
(1.57 to 5.24)
DataMatrix 0.13 (5) 0.5 x 0.5
(0.20 x0.20)
5.0 to 7.5
(1.96 to 2.95)
0.8 x 0.8
(0.31 x 0.31)
0.25 (10) 4.5 to 10.5
(1.77 to 4.13)
Skew ±40°
Pitch ±35°
Rotation 360°
Print Contrast (Min.) 27%
* Reading distances are measured from the nose of the reader.
