Datalogic MAGELLAN 1000I User Manual

Getting Started
1-4 Magellan
®
1000i
LED and Beeper Indicators
The scanner’s beeper sounds and its green LED illuminates to indicate various functions
or errors on the scanner. The tables below list these indications. One exception to the
behaviors listed in the tables is that the scanner’s functions are programmable, and may
or may not be turned on. For example, certain indications, such as the power-up beep
can be disabled using programming barcode labels.
Green LED Indications
LED
INDICATION
INDICATION COMMENT
Power-on
indication
Bright green flash
Indicates the scanner has finished all its power up tests and is
now ready for ooperation.
Good Read
Indication
Bright green flash Indicates a barcode has been read and decoded.
Scanner Ready Constant dim green The scanner is ready for operation.
Sleep Mode
Constant green flash
(100mS on, 1900mS off)
The scanner is in Sleep Mode. To wake the scanner up, move
an object in front of its window or press the button atop the
unit.
Host Disable
Constant green flash at 1 Hz
(100mS on, 900mS off)
The scanner is disabled due to receiving a disble command
from the POS terminal.
Diagnostics
Varies (see "Error Codes" on
page 1-5 for more information)
The LED can provide diagnostic feedback if the scanner dis-
covers a problem during SelfTest.
BEEPER FUNCTIONS
BEEPER
INDICATION
INDICATION COMMENT
Power On Beep Single beep
The Power-On LED indication is a configurable feature which
can be enabled or disabled. When enabled, this beep Indi-
cates the scanner has finished all its power up tests and is
now ready for operation.
Good Read
Indication
Single beep
The good read beep indication is configurable. Options
include: Enable/disable, frequency, duration and volume. See
the Product Reference Guide (PRG) for more information.
Diagnostics
Varies (see "Error Codes" on
page 1-5 for more information)
The Beeper can provide diagnostic feedback if the scanner
discovers a problem during SelfTest.
Programming
Mode
Indications
Varies (see the Product Reference
Guide for more information about
scanner programming)
The Beeper will sound as programming barcode labels are
scanned, indicating progress during scanner configuration.

Datalogic MAGELLAN 1000I Specifications

General

Tilt angle range	0 - 360 °
Decoding standards	1D / Linear Codes: - Autodiscriminates all standard 1D codes including GS1 DataBar linear codes 2D Codes: - Data Matrix Stacked Codes: - GS1 DataBar Expanded Stacked - GS1 DataBar Stacked - GS1 DataBar Stacked Omnidirectional - PDF417
Optical sensor resolution	752 pixels
Standard interfaces	Keyboard wedge, USB, RS-232, RS-485
Input voltage	8.0 - 14.0 V
Power consumption	400 mA
Dimensions (WxDxH)	71 x 94 x 84 mm
Maximum operating distance	0.171 m
Product color	Gray
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	5 - 55 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	198.5 g
