Datalogic MAGELLAN 1000I User Manual

D-2 Magellan
®
1000i
Interface Default Exceptions
The factory default settings indicated in the programming sections (in bold text) reflect factory configuration for
the RS-232 standard interface. The following tables list default exceptions by interface for the remaining available
interfaces.
IBM Interfaces
IBM Interfaces include USB-OEM, IBM Port 9B, IBM Port5B and IBM Port17.
Parameter Default Setting
IBM Interface Type IBM Port 9B
Number of Host Transmit Buffers One Buffer
Label I.D. Transmission Disable
Suffix Characters No Suffix

Datalogic MAGELLAN 1000I Specifications

General

Tilt angle range	0 - 360 °
Decoding standards	1D / Linear Codes: - Autodiscriminates all standard 1D codes including GS1 DataBar linear codes 2D Codes: - Data Matrix Stacked Codes: - GS1 DataBar Expanded Stacked - GS1 DataBar Stacked - GS1 DataBar Stacked Omnidirectional - PDF417
Optical sensor resolution	752 pixels
Standard interfaces	Keyboard wedge, USB, RS-232, RS-485
Input voltage	8.0 - 14.0 V
Power consumption	400 mA
Dimensions (WxDxH)	71 x 94 x 84 mm
Maximum operating distance	0.171 m
Product color	Gray
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	5 - 55 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	198.5 g
