Datalogic MAGELLAN 1000I

Symbologies
5-30 Magellan
®
1000i
Code 39 Length 1, Length 2 Programming Instructions
1. Scan the START/END barcode.
2. Scan either the Set Length 1 or Set Length 2 barcode.
3. Turn to
Appendix C, Alpha-Numeric Pad and scan the three digits (zero padded) represent-
ing the length in decimal notation.
4. Scan the START/END barcode.
Quiet Zones
This feature enables/disables the requirement that quiet zones must be present for Code 39 bar-
codes.
NOTE
For Code 39 barcodes, all check, data and full ASCII
shift characters are included in the length calculations.
Start/Stop characters are not included.
START / END
PROGRAMMING BARCODES
DEFAULT SETTING FOR THIS FEATURE: 003
Set Length 1
Set Length 2
DEFAULT SETTING FOR THIS FEATURE: 050
START / END
PROGRAMMING BARCODES
Don’t require Quiet Zones
DEFAULT
Require Quiet Zones
³0 01
