Product Reference Guide F-1
Chapter F
Host Commands
Accepting RS-232 Commands
The scanner responds to the following RS-232 commands:
If one of the above commands is received, the scanner will perform the steps indicated for the command. Host
commands for other interfaces are also available. Contact Tech Support for more details.
COMMAND ASCII HEX COMMENT
Enable Scanner E 0x45
Disable
Scanner
D0x44
Reset Scanner R 0x52
Not On File
Indication
F 0x46 Long series of beeps
Beep Good
Read Tone
B 0x42 Beeps if Good Read Beep is enabled
Force Good
Read Tone
! 0x01 Beeps regardless of beep setting
Bel ‘ 0x07 Force Good Read Tone
Identification
request
i0x69
Returns long response
a
a. Call Tech Support for information.
Health request h 0x68
Returns long response
a
Status request s 0x73
Returns long response
a

Datalogic MAGELLAN 1000I Specifications

General

Tilt angle range	0 - 360 °
Decoding standards	1D / Linear Codes: - Autodiscriminates all standard 1D codes including GS1 DataBar linear codes 2D Codes: - Data Matrix Stacked Codes: - GS1 DataBar Expanded Stacked - GS1 DataBar Stacked - GS1 DataBar Stacked Omnidirectional - PDF417
Optical sensor resolution	752 pixels
Standard interfaces	Keyboard wedge, USB, RS-232, RS-485
Input voltage	8.0 - 14.0 V
Power consumption	400 mA
Dimensions (WxDxH)	71 x 94 x 84 mm
Maximum operating distance	0.171 m
Product color	Gray
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	5 - 55 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	198.5 g
