MSI/Plessey Enable
Product Reference Guide 5-269
MSI/Plessey Fixed Length 2
This feature specifies MSI/Plessey second fixed length.
To set this feature:
1. Scan the SWITCH bar code.
2. Scan the bar code,
SET MSI/PLESSEY FIXED LENGTH 2 below.
You’ll need to cover any unused bar codes on this and the facing
page to ensure that the scanner reads only the bar code you intend
to scan.
3. Scan the appropriate digits from the keypad in
Appendix C that rep-
resent the desired fixed label length. The selectable range for this
option is 0 (zero), or 4 to 16. Pad all single digit numbers with a
leading zero to yield a two-digit entry (00, 04-16).
4. Complete the programming sequence by scanning the SWITCH
bar code.
SET MSI/PLESSEY FIXED LENGTH 2
NOTE
This applies when MSI/Plessey Length Control is set to fixed-
length decoding.
If Fixed Length 2 is set to 00 (zero), then Fixed Length 1 will
apply.
