Datalogic Magellan 2200VSΩ Product Reference Guide

Product Reference Guide B-5
Auxiliary Port
External Handheld Input
Connector Hardware
RJ45, 10 Position
Cable Pinout
Table B-4
PIN # FUNCTION DESCRIPTION
1 DTR Data Terminal Ready
2 CTS in Clear To Send (input)
3 N/C No Connection - Reserved
4 RTS out Request To Send (output)
5 RxD in Receive Data (Input)
6 TxD out Transmit Data (output)
7 ~EAS_GOOD READ Special use Good Read
8 +5V out (500mA max) +5V out
9 GND Signal Ground
10 SPKR OUT Speaker Out
