Datalogic Magellan 2200VSΩ Product Reference Guide

Product Reference Guide A-1
Appendix A
LED/Beeper Indications & Controls
Figure A-1 shows the operator’s controls and indicators for both models.
The descriptions following identify the use or function of each compo-
nent.
Figure A-1. Scanner Controls and Indicators
Volume/Tone Push Button
The Volume/Tone Push Button also performs multiple functions depend-
ing upon the duration of time it is pressed:
Speaker
Scan
Window
U
pp
er Sca
n
Win
dow
Lower
S
ca
n
Win
dow
Indicator
LED plus
Volume/Tone
Push Button
Volume/Tone
P
us
h B
u
tt
on
In
d
i
ca
t
o
r LE
D
Model 2200VS
Model 2
300
H
S
To
p
Cove
r
NOTE
Volume changes made using the Volume/Tone Push Button are lost
when the scanner is powered-down and are reset to the configured set-
ting. If you wish to permanently change the volume, use the special
programming labels in the Product Reference Guide.

Datalogic Magellan 2200VSΩ Specifications
