Interface Related Features
Product Reference Guide 5-45
PC Keyboard Wedge Interface Selection
This scanner supports a variety of PC Keyboard interfaces. The table
below defines the different interface selections. Scan the corresponding
bar code starting on page 5-46 to select the desired keyboard interface.
I/F Type PCs Supported Page
A PC/XT w/Alternate Key Encoding 5-46
B AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95 w/Alternate Key Encoding 5-46
C PS/2 25 and 30 w/Alternate Key Encoding 5-47
D PC/XT w/Standard Key Encoding 5-47
E AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95 w/Standard Key Encoding 5-48
F PS/2 25 and 30 w/Standard Key Encoding 5-48
G IBM 3xxx w/122 keyboard 5-49
H IBM 3xxx w/102 keyboard 5-49
I PS/55 5530T w/104 keyboard 5-50
J NEC 9801 5-50
NOTE
We recommend you disconnect power before plugging/unplugging cables to
avoid any possibility of equipment damage.
