6-50 Magellan
®
8500 Scanner
Interface Related Features
Interface Type
Specifies the current scanner interface. Selections are:
INTERFACE TYPE
INTERFACE IDENTIFICATION NUMBER
a
a.To access a scanner’s interface identification number, place the
scanner in Scanner Diagnostic Mode and view the 7-segment FRU
display (reference Scanner Diagnostic Mode in Section 2 for more
information).
RS-232 Standard 05
RS-232 Wincor-Nixdorf 12
RS-232 Single Cable 20
IBM USB 45
IBM
Port 17
04
NOT USER-SELECTABLE
Null Interface
Indicated by 7-segment FRU display flashing
0 at start-up
NOTE
A new scanner may have been shipped from the factory with a Null Inter-
face (no interface type selected) to ensure system compatibility at instal-
lation. In this case, the correct Interface Type programming bar code must
be scanned first before the scanner can be used with a POS system.
NOTE
If the scanner’s interface type must be changed, always be sure that inter-
face configuration is the FIRST item scanned during a programming ses-
sion. (Selecting an interface type resets ALL other configuration items to
the factory default for that interface type.)
