Datalogic MAGELLAN 8500 User Manual

2-24 Magellan
®
8500 Scanner
Viewing Angle
The optimum viewing angle is directly facing the customer. To ensure that
the display is easily readable for the majority of your customers, the dis-
play should be approximately 48 to 60” (122 to 152 cm) from the floor.
Figure 2-12. Remote Scale Display
NOTE
Check with local Weights and Measures authorities regarding proper posi-
tioning of scale displays used in retail trade.
CAPACITY / CAPACITE - 30 X .01 lb / 15 x .005 kg
0.00 lb
40˚
40˚
25˚
25˚
