1-4 Magellan
®
8500 Scanner
Scanner and Scanning-Scale Nomenclature
Controls, indicators and other nomenclature are shown in Figure 1-1.
Figure 1-1. Scanning-Scale Nomenclature
Produce Rail
All Weighsâ„¢ Platter
Green LED
Yellow LED
Wei
g
hin
g
Surface — Lean
O
versize Produce Her
e
Vertical Window
Horizont
a
l Win
d
o
w
Scale Zero
Push Button
Bonnet
Volume
/
Tone Push Butto
n
