6-112 Magellan
®
8500 Scanner
Single Cable RS-232 Datalogic Extensions
When Datalogic
1
extensions are enabled, scale calibration mode informa-
tion is communicated to the host. Contact Customer Support for the for-
mat of this information. Choices for this feature are:
• Standard Protocol
• Support Datalogic Extensions to Protocol
To set this feature:
1. Scan the SWITCH bar code.
2. Scan your selection from the bar codes below. You’ll need to cover
any unused bar codes on this and the facing page to ensure that
the scanner reads only the bar code you intend to scan.
3. Complete the programming sequence by scanning the SWITCH
bar code.
SINGLE CABLE RS-232 DATALOGIC EXTENSIONS = STANDARD PROTOCOL
SINGLE CABLE RS-232 DATALOGIC EXTENSIONS = SUPPORT DATALOGIC
EXTENSIONS TO PROTOCOL
1. Depending upon when your scanner was purchased, this could be termed, a “PSC extension.”
