Product Reference Guide E-5
Single Cable RS-232
Datalogic Extensions
0 (std
protocol)
UPC-A Enable 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable)
UPC-A Number Sys-
tem Character Trans-
mission
0 (disable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable)
UPC-A Check Charac-
ter Transmission
1 (enable) 1 (enable) 1 (enable) 0 (disable) 1 (enable) 1 (enable)
Expand UPC-A to EAN-
13
0 (disable) 0 (disable) 1 (enable) 0 (disable) 0 (disable) 0 (disable)
UPC/EAN AIM ID 0 (disable) 0 (disable) 0 (disable)
UPC-A Label ID 4100("A") 4100("A") 4100("A") 4100("A")
UPC-A 2-Digit Supple-
mental Label ID
4100("A") 4100("A") 4100("A") 4100("A")
UPC-A 5-Digit Supple-
mental Label ID
4100("A") 4100("A") 4100("A") 4100("A")
UPC-A 128 Supplemen-
tal Label ID
4100("A") 4100("A") 4100("A") 4100("A")
UPC-E Enable 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable)
UPC-E Number Sys-
tem Character Trans-
mission
1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable)
UPC-E Check Charac-
ter Transmission
0 (disable) 0 (disable) 0 (disable) 0 (disable) 1 (enable) 1 (enable)
Expand UPC-E to UPC-
A
0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
Expand UPC-E to EAN-
13
0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
UPC-E Label ID 4500("E") 4500("E") 4300("C") 4500("E")
Aux RS-232
Wincor-
Nixdorf
Single
Cable
IBM 17 IBM USB
