MATRIX 210™ QUICK GUIDE
15
STEP 5 – INSTALLING VISISET™ CONFIGURATION PROGRAM
VisiSet
™
is a Datalogic reader configuration tool providing several important advantages:
• Setup Wizard for rapid configuration and new users;
• Defined configuration directly stored in the reader;
• Communication protocol independent from the physical interface allowing to consider the reader as a remote object to be
configured and monitored.
To install VisiSet™, turn on the PC that will be used for the configuration, running Windows 98, 2000/NT, XP, Vista or 7, then
insert the VisiSet™ Mini-DVD, wait for the DVD to autorun and follow the installation procedure.
This configuration procedure assumes a laptop computer, running VisiSet™, is connected to the reader's auxiliary port.
After installing and running the VisiSet™ software
program the following window appears:
Set the communication parameters from the "Options" menu. Then
select "Connect", the following window appears:
Figure 11 - VisiSet™ Opening Window Figure 12 - VisiSet™ Main Window After Connection
