Datalogic Matrix 210 Quick Reference Guide

MATRIX 210™ QUICK GUIDE
10
STEP 2 – MOUNT AND POSITION THE READER
1. To mount the Matrix 210™, use the mounting bracket to obtain the most suitable position for the reader. Two of the most
common mounting configurations are shown in the figures below. Other mounting solutions are provided in the Matrix 210™
Reference Manual.
Figure 4 –Positioning 90° Model with Mounting Bracket Figure 5 –Positioning Straight Model with Mounting Bracket
Tilt
Pitch
Tilt
Pitch
