MATRIX 210™ QUICK GUIDE
25
READING FEATURES
Reading Distance
(3)
mm (in)
MODELS
Focus
Distance
mm (in)
Field of View
(1)
mm (in)
PPI
(2)
Typ. Linear and
Stacked Code
Resolution mm
(mils)
2D Code Resolution
mm (mils)
min. max.
Max. 0.076 (3) 28 (1.10) 32 (1.26)
214-xxx UHD
30
(1.18)
16.5 × 10.5
(0.65 × 0.41)
1150 0.063 (2.5)
Typ. 0.13 (5) 23 (0.91) 38 (1.50)
Max. 0.13 (5) 42 (1.65) 53 (2.08)
211-xxx NEAR
45
(1.77)
35 × 22
(1.38 × 0.87)
545 0.10 (4)
Typ. 0.19 (7.5) 36 (1.42) 61 (2.40)
Max. 0.19 (7.5) 54 (2.13) 90 (3.54)
212-xxx MEDIUM
65
(2.56)
50 × 32
(1.97 × 1.26)
380 0.15 (6)
Typ. 0.25 (10) 47 (1.85) 101 (3.97)
Max. 0.25 (10) 85 (3.35) 135 (5.31)
213-xxx FAR
105
(4.13)
80 × 50
(3.15 × 1.97)
238 0.20 (8)
Typ. 0.38 (15) 70 (2.76) 192 (7.55)
(1)
@ Focus Distance
(2)
Pixels per inch @ Focus Distance
(3)
Measurement Conditions:
• Test Chart: provided with the reader
• Still code at the center of the FOV
• Code Symbology: Data Matrix ECC 200
• Tilt Angle: 45°
• Skew Angle: 15°
• Image Processing Mode = Advanced Code Setting
• Module Size (mils) equal to the resolution of the code to read
• Image Processing Self Tuning = Enabled
• Image Processing Self Tuning Mode = Code Contrast Levels Only *
• Image Acquisition Self Tuning = Enabled (for 213-xxx models only)
* This parameter setting can increase the image processing time.
All distances are measured from the reading window to the code surface.
Depending on the code resolution, symbology and number of characters in the code, the Reading Area can be different from the FOV.
