MATRIX 210™ QUICK GUIDE
29
MECHANICAL DIMENSIONS
45
[1.76]
10.0
[0.39]
25.0
[0.98]
11.0
[0.43]
25
[0.98]
50
[1.97]
7
[0.29]
6
[0.25]
32
[1.25]
9.0
[0.36]
25.0
[0.98]
7
[0.29]
M3X4
n°4
25
[0.98]
45
[1.76]
54
[2.13]
14
[0.55]
Figure 17 – Matrix 210™ Overall Dimensions - Straight and 90° Reading Window Models
mm
[in]
OPTICAL
AXIS
OPTICAL AXIS
