MATRIX 210™ QUICK GUIDE
31
PATENTS
This product is covered by one or more of the following patents:
U.S. patents: 6,512,218 B1; 6,616,039 B1; 6,808,114 B1; 6,997,385 B2; 7,102,116 B2; 7,282,688 B2
European patents: 999,514 B1; 1,014,292 B1; 1,128,315 B1.
Additional patents pending.
COMPLIANCE
See the Matrix 210™ Reference Manual for the Declaration of Conformity.
Only connect Ethernet and dataport connections to a network which has routing only within the plant or building and no routing
outside the plant or building.
EMC COMPLIANCE
In order to meet the EMC requirements:
• connect reader chassis to the plant earth ground by means of a flat copper braid shorter than 100 mm;
• connect pin "Earth" of the CBX connection box to a good Earth Ground;
• for direct connections, connect the main interface cable shield to pin 1 of the 25-pin connector.
