Datalogic Matrix 210 Quick Reference Guide

MATRIX 210™ QUICK GUIDE
26
TECHNICAL FEATURES
ELECTRICAL FEATURES Matrix 210 21x-x0x models Matrix 210 21x-x1x models Matrix 210 21x-x2x models
Power
Supply Voltage 10 to 30 Vdc 10 to 30 Vdc 5 Vdc
Consumption
0.35 to 0.13 A, 3.9 W max
0.16 A @ 24 V
0.4 to 0.15 A, 4.5 W max
0.18 A @ 24 V
0.5 A, 2.5 W max
Communication Interfaces
Main
- RS232
- RS485 full-duplex
- RS485 half-duplex
2400 to 115200 bit/s
2400 to 115200 bit/s
2400 to 115200 bit/s
2400 to 115200 bit/s
2400 to 115200 bit/s
2400 to 115200 bit/s
Auxiliary - RS232 2400 to 115200 bit/s 2400 to 115200 bit/s
ID-NET™ Up to 1MBaud Up to 1MBaud
Ethernet
- 10/100 Mbit/s
Inputs: Input 1(External Trigger)
and Input 2
Opto-coupled and polarity
insensitive
Opto-coupled and polarity
insensitive
Outputs: Output 1 and Output 2
Opto-coupled Opto-coupled
USB 2.0 up to 921600 bit/s
OPTICAL FEATURES
Image Sensor CMOS sensor with Global Shutter
Image Format WVGA (752x480)
Frame Rate up to 60 frames/sec. @ full window size
Pitch
± 35°
Tilt 0° - 360°
Lighting System Internal Illuminator
LED Safety Class Class 1 to EN60825-1
PHYSICAL FEATURES Matrix 210 21x-1xx models Matrix 210 21x-0xx models
Dimensions 50 x 25 x 45 mm (1.97 x 0.98 x 1.77 in) 54 x 32 x 45 mm (2.13 x 1.26 x 1.77 in)
Weight 190 g. (6.7 oz.) with cable
Material Aluminium alloy

Datalogic Matrix 210 Specifications

General

Brand	Datalogic
Model	Matrix 210
Category	Barcode Reader
Language	English
