Symbologies Enter/Exit Programming Mode

Product Reference Guide

215

ISBT 128 Dynamic Concatenation Timeout

Specifies the timeout used by the ISBT 128 Dynamic Concatenation Mode.

$CI8DT05

ISBT 128 Dynamic Concatenation Timeout = 50 msec

$CI8DT0A

ISBT 128 Dynamic Concatenation Timeout = 100 msec

$CI8DT14

ISBT 128 Dynamic Concatenation Timeout = 200 msec

$CI8DT32

ISBT 128 Dynamic Concatenation Timeout = 500 msec

$CI8DT4B

ISBT 128 Dynamic Concatenation Timeout = 750 msec

$CI8DT64

ISBT 128 Dynamic Concatenation Timeout = 1 second

DEFAULT
