Reading Parameters Enter/Exit Programming Mode

Product Reference Guide

Green Spot Duration

Specifies the duration of the good read pointer beam after a good read.

$CLSSP00

Green Spot Duration = Disable (Green Spot is Off)

$CLSSP01

Green Spot Duration = Short (300 msec)

$CLSSP02

Green Spot Duration = Medium (500 msec)

$CLSSP03

Green Spot Duration = Long (800 msec)

DEFAULT
