RS-232 ONLY Interface Enter/Exit Programming Mode
Product Reference Guide
29
Parity
This feature specifies parity required for sending and receiving data. A parity
check bit is the most significant bit of each ASCII coded character. Select the
parity type according to host device requirements.
• Select None when no parity bit is required.
• Select Odd parity and the parity bit value is set to 0 or 1, based on data, to
ensure that an odd number of 1 bits are contained in the coded character.
• Select Even parity and the parity bit value is set to 0 or 1, based on data, to
ensure that an even number of 1 bits are contained in the coded character.
$CR2PA00
Parity = None
$CR2PA01
Parity = Even
$CR2PA02
Parity = Odd
DEFAULT
To Next Page
