GS1 DataBar (RSS)

Product Reference Guide

333

GS1 DataBar (RSS)

GS1 DataBar-14

NOTE

GS1 DataBar variants must be enabled to read the bar codes below

(see "

GS1 DataBar (RSS)" on page 333

10293847560192837465019283746029478450366523

(GS1 DataBar Expanded Stacked)

1234890hjio9900mnb

(GS1 DataBar Expanded)

08672345650916

(GS1 DataBar Limited)

55432198673467

(GS1 DataBar Omnidirectional Truncated)

90876523412674

(GS1 DataBar Omnidirectional Stacked)

78123465709811

(GS1 DataBar Omnidirectional Stacked)
