Datamax A-4310 User Manual

Immediate Command Functions
Class Series Programmer’s Manual 11
Where:
Possible Values Interpretation Byte Transmit Sequence
a - Y/N Y = Interpreter busy (imaging) 1
b - Y/N Y = Paper out or fault 2
c - Y/N Y = Ribbon out or fault 3
d - Y/N Y = Printing batch 4
e - Y/N Y = Busy printing 5
f - Y/N Y = Printer paused 6
g - Y/N Y = Label presented 7
h - N N = Always No 8
- : : = Always : 9
i - Y/N Y = Cutter Fault 10
j - Y/N Y = Paper Out 11
k - Y/N Y = Ribbon Saver Fault 12
l - Y/N Y = Print Head Up 13
m - Y/N Y = Top of Form Fault 14
n - Y/N Y = Ribbon Low 15
o - Y/N Y = N (reserved for future) 16
p - Y/N Y = N (reserved for future) 17
Table 3-1: ASCII Status Bytes
SOH B Toggle Pause
This command toggles the printer’s paused state between on and off. (This is the same function
achieved by pressing the PAUSE Key on the printer.)
Syntax:
<SOH>B
Sample:
<SOH>B
Printer Response: This command will illuminate the Paused/Stop Indicator and/or indicate
PAUSED on the LCD or graphics display panel, suspend printing, and wait
until one of the following occurs:
 The <SOH>B command is sent to the printer.
 The PAUSE Key is pressed.
Upon which the printer will turn the Paused/Stop Indicator ‘Off’ and/or
remove PAUSED from the LCD or graphics display panel, then resume
operation from the point of interruption. (If the Receive Buffer is not full,
an <XON> character will be transmitted from the printer.)

Datamax A-4310 Specifications

General

Print Resolution	300 dpi
Print Speed	10 ips
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Print Technology	Thermal Transfer
Memory	16 MB DRAM / 8 MB Flash
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Tickets
Maximum Print Length	99 inches
Supported Barcode Types	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, Interleaved 2 of 5, Codabar, Postnet, PDF417
Operating Temperature	40°F to 104°F (4°C to 40°C)
Print Width	4.16" (105.7 mm)
Media Width	1.0" to 4.65" (25.4 mm to 118.1 mm)
Media Thickness	0.0025" to 0.010" (0.0635 mm to 0.254 mm)

Summary

Overview

Who Should Use This Manual

Identifies the intended audience for this manual, focusing on programmers creating label software.

Scope of the Programmer's Manual

Explains the manual's coverage of DPL commands for Datamax printers and firmware versions.

Control Code Command Functions

Attention-Getters Explained

Describes standard ASCII control labels representing one-character control codes for commands.

Alternate Control Code Modes

Explains available alternate modes for transmitting control codes when standard codes are unavailable.

Immediate Command Functions

SOH # Reset Command

Resets the printer to default settings, clearing buffers and DRAM memory.

SOH A Send ASCII Status String

Allows the host to check current printer status by returning an eight-character string.

SOH C Stop/Cancel Command

Clears the print buffer, pauses the printer, and illuminates the Paused/Stop Indicator.

SOH F Send Status Byte

Instructs the printer to send a single status byte representing printer status flags.

System-Level Command Functions

STX A Set Time and Date

Sets the printer's internal time and date, stored in the inch counter.

STX I Input Image Data

Precedes image downloading, allowing the printer to receive image data from a host.

STX M Set Maximum Label Length

Sets the media distance to search for top-of-form before declaring a paper fault.

STX Q Clear All Modules

Clears all Flash and DRAM modules, destroying all stored data.

STX W Request Memory Module Information

Requests a memory module directory listing, showing results based on printer class and firmware.
