Chapter 4 – Maintenance and Adjustments 29
Cleaning Card Procedure
If printing with direct thermal media, thermal transfer media with wax/resin ribbon combinations, or if the
Cotton Swab technique was not successful, clean the printhead as follows:
1) Open the printer. Wait briefly for the Printhead to cool.
2) Remove media and ribbon then place a Cleaning Card under the Printhead (part number 70-2013-
01).
3) Close the cover then press the Button to initiate cleaning.
4) After the cleaning card has been run through the printer, reinstall media (and ribbon, if needed).
Plug in and turn ON the printer. Run a few sample labels and examine them. If streaking is still
present, use the Cleaning Film Procedure, below; otherwise, this completes cleaning.
Cleaning Film Procedure
If printing with thermal transfer media and resin ribbon, when printing with a Heat Value of 22 or higher, or
when other methods prove unsuccessful, clean the printhead as follows:
1) Open the printer. Wait briefly for the Printhead to cool..
2) Remove media and ribbon then place a sheet of Cleaning Film under the Printhead (part number
70-2087-01).
3) Close the cover then press
Button to initiate cleaning.
4) After the cleaning film has been run through the printer, turn OFF the Power Switch and unplug
the printer. Open the cover and wait briefly for the Printhead to cool. Using a cotton swab
moistened (not soaked) with isopropyl alcohol, clean the Printhead then allow it to dry.
5) Reinstall media (and ribbon, if needed). Plug in and turn ON the printer. Run a few sample labels
and examine them. If streaking is still present, the Printhead may need to be replaced; see
Section 4.2
