H-Class 23
L. Route the media back into the printer and around the media core (as shown below) then
tape the leading edge to the media core.
M. Enter the menu, go to PRINTER OPTIONS / REWINDER, and select Enable. Exit the menu
and save your changes. (The rewinder will turn slowly for about 30 seconds to tension
the material and afterward rotate as labels are advanced.)
;
If dispensing narrow or small labels using a Peel and Present option, the following
settings may require adjustment:
• To maintain Top Of Form accuracy, it may be necessary (depending upon the
print speed) to reduce the torque; see PRINTER OPTIONS / REWINDER
ADJUSTMENT.
• To maintain image sizing accuracy, it may be necessary to adjust CUSTOM
ADJUSTMENTS / ROW ADJUST to a negative value.
For example, while peeling 2 inch wide by 1 inch long labels using an H-8308, the
following settings were used to maintain accuracies; your results may vary:
Print Speed (IPS) Rewinder Adjustment Row Adjust
2 -30%
4 -20%
6 -10%
8 -10%
-40 Dots
