Datamax Mark II M-4206 User Manual

ii
4.2 Buttons ......................................................................... 18
4.3 Normal Mode - Button Functions.................................. 19
4.4 Express Setup Mode - Button Functions...................... 20
4.5 Printer Setup Mode - Button Functions ........................ 21
4.5.1 Printer Setup Menu List...................................... 22
4.5.2 Menu Items and Values ..................................... 23
4.5.3 Step by Step Modification of the Printer Setup .. 26
4.6 Label Alignment............................................................ 28
4.6.1 Label Alignment = YES ...................................... 28
4.6.2 Label Alignment = AUTO ................................... 29
4.6.3 Label Alignment = NO........................................ 29
4.6.4 Label Alignment Troubleshooting....................... 30
4.7 Calibration Mode – Button Functions ........................... 32
4.7.1 Auto Media Sensor Calibration .......................... 33
4.7.2 Manual Media Sensor Calibration...................... 34
4.8 Internal Labels.............................................................. 35
4.8.1 Database Configuration and Test Labels........... 35
4.8.2 Test Label .......................................................... 37
Using the Front Panel (Display-equipped printers)
5.0 Introduction................................................................... 39
5.0.1 Ready Mode....................................................... 39

Datamax Mark II M-4206 Specifications

General

Print Resolution	203 dpi
Type	Label Printer
Print Method	Thermal Transfer
Max Print Speed	6 inches per second
Memory	16 MB SDRAM, 8 MB Flash
Interfaces	USB, Serial, Parallel
Media Width	4.5 inches
Media Length	0.25" to 99"
Max Print Width	4.25 inches (108 mm)
