WiFi Configuration Page
WLAN Network Settings
SSID Service Set Identifier that identifies the Module to connect to an AP. To make this
connection, the Module and AP must have the same SSID. The SSID cannot contain
spaces. Default setting is the MAC address of the wireless module.
WLAN Network Type Specifies the type of network in which the Module will be used:
Infrastructure = connects to WLAN using an AP.
Ad Hoc = used to connect two peer-to-peer devices.
Unique = resets card to Adhoc Mode and uses the MAC address as the SSID
(default)
Ad Hoc Mode Channel When Wireless Network Type is Ad Hoc, selects the channel used for communication.
The two peer-to-peer devices must use the same channel. Range is 1 to 14 channels.
Default channel is 1.
Access Point Density
Specifies a rate that, if not sustainable with the current association, causes the Module
to look for an AP with which it can maintain the specified rate. A high setting causes the
Module to more readily switch to another AP.
Low = 2 Mbps cannot be sustained. (default)
Medium = 5.5 Mbps cannot be sustained.
High = 11 Mbps cannot be sustained.
WLAN Region Code
Module Operation Region
Specifies the wireless channels allowed. This setting only applies when the Module is
operating in Ad Hoc Mode. The AP controls the channel used during Infrastructure
Mode. Default is US.
WLAN Security Settings
Wireless Security Mode
Configures the security settings.
Disable = security is disabled. (default)
wep64 = 64-bit key length (sometimes referred to as 40-bit)
wep128 = 128-bit key length
wpa-psk = WPA Pre-Shared Key
wpa-leap = WPA LEAP
wpa-leap64 = Migration Mode w/ Cipher suite TKIP+40 bit WEP using EAP(LEAP).
Requires LEAP username and password.
wpa-leap128 = Migration Mode w/Cipher suite TKIP+128 bit WEP using EAP(LEAP).
Require LEAP username and password.
wpa-psk64 = Migration Mode w/Cipher suite TKIP+40 bit WEP using WPA PSK.
Requires WPA Passphrase.
wpa-psk128 = Migration Mode w/Cipher suite TKIP+128 bit WEP using WPA PSK.
Requires WPA Passphrase.
WPA Passphrase
(Preshared Key)
Enter your WPA passphrase.
Re-enter Passphrase Confirms WPA passphrase entry
Leap User ID User ID for Leap security mode
Leap Password Password for Leap security mode
Re-enter Leap Password Confirm password for Leap security mode
WEP Authentication Enables or disables WEP authentication:
Automatic = automatically detects the authentication. (default)
Open System = communicates the key across the network.
Shared Key = allows communication only with devices with identical WEP settings.
Default Key Selects the default WEP Key from 1 – 4 if Shared Key or Both is selected for WEP
Authentication. Default is WEP Key 1.
WEP Key 1 through 4 Specify up to four WEP Key values:
If WEP Encryption = 64, enter 10 hexadecimal digits for each key.
If WEP Encryption = 128, enter 26 hexadecimal digits for each key.
