AP25 Installation and Operating Guide Version 1.00
Appendix D: AP25 Product Specifications D-1 Document #: 9301H79500 Ver. 1.00
Appendix D: AP25 Product Specifications
Digital Audio Decoders
Dolby
Dolby AC3
DTS
DTS-HD Master Audio / DTS ES / DTS 5.1 / Neo:6
Signal Inputs
Digital Audio Inputs
Channels: 16
Connectors: Two DB25 Female (Ch1-8 and 9-16)
Digital Format: AES/EBU
Sample Rates: 44.1kHz, 48kHz, 96 kHz and 192kHz
Other Digital Audio Inputs
Connectors: Two TOSLINK (optical S/PDIF) and 1 coaxial (S/PDIF)
Analog Audio Inputs
Channels: 8 balanced, can be connected unbalanced
Connector: DB25 (Female)
Impedance: 10k ohms
Sensitivity: 300mv RMS
Other Analog Audio Inputs
Channels: 2 stereo single ended input pairs
Connector: 4 RCA jacks
Impedance: 10k ohms
Sensitivity Adjustable: -16dBv to -4dBv
Microphone Input
Single channel -68dBv to -8dBv input with switchable +48V phantom power
Connector: XLR female
HDMI Audio & Video Inputs
Audio Channels: Up to 8 channels (LPCM, DTS-HD Master Audio & Dolby AC3)
Connectors: 5 HDMI connectors (4 switched as inputs and 1 as output)
HDMI 2.0 compliant digital audio with video pass-thru. HDCP 2.2 supported on the output and
input #4.
