3.0 How-To Procedures for Setup
This table provides a list of setup activities and provides instructions or a link to instructions elsewhere
in this manual.
Table 11. Setup Procedures
ACTIVITY INSTRUCTIONS
Assign a Format button See 4.3.4 Assign Format Buttons, page 65.
Unassign / delete a Format
button
See 4.3.4 Assign Format Buttons, page 65 – select the button
and assign a “blank” format to it.
Configure power-on Format
(Startup Format)
See 4.3.2 Startup Format, page 63.
Assign fader level to a Format
or set global fader for all
Formats
See 4.2 System Setup Screen, page 51 “Fader Control”, and see
0
Assign F
ader Level to a Format, page 52.
Create a Format See 3.1 Example: Creating a Format, below.
For detailed information about Formats, see  About Formats,
pag
e 27.
Assign Channel Names and Vu
meters
See 4.3.8.3 Channel Names, page 86.
Set Non-sync Level and Non-
sync Routing
See 4.3.6.3 NonSync Level and Routing, page 72.
See also 0
Assign F
ader Level to a Format, page 53.
USB Save / Restore / Load See 4.2.3 Saving and Restoring Configuration Files, page 56.
Load a personalized screen
saver
See 4.2.3 Saving and Restoring Configuration Files, page 56. To
set screensaver time and mode, see 4.2 System Setup Screen,
pag
e 51.
Set up Global Audio Delay for a
format
See 4.3.6.1 Global Delay, page 69.
Set up Multiple Surround
Channels
For digital cinema format, see 4.3.6.2 Extended Surround
Options, page 71.
Set up HDMI option For digital cinema format, see HDMI Options, page 76
View AP25 System information See 4.2.5 System Info, page 59.
Update AP25 software See 4.2.2 Updating AP25 Software, page 54.
3.1 Example: Creating a Format
Prior to creating a format, it is necessary to identify the following:
 Input source
 Format option
 EQ set up
 Output channel profile name
