AP25 Installation and Operating Guide Page 14
AP25 Installation & Operating Guide Document # 9301H79500 Ver. 1.00
1.0 Operating AP25
1.1 How-To Procedures – Operations
ACTIVITY INSTRUCTIONS
Turn Power ON Press and release the power button on the front panel. If the unit will not
power up, be sure that the rear panel power switch is ON and the unit is
plugged into a working AC outlet protected by a surge protector. See
Powering ON the AP25 Processor, page 16.
Turn Power OFF Press and release the power button on the front panel.
Adjust volume Turn the master fader knob on the front panel to adjust volume on all
channels. Turn clockwise to increase volume. See Adjusting the Fader,
pag
e 18.
Select a format Touch the desired format in the bottom row of the AP25 display. If the
format you want is not shown, then that format is not available. See The
Ho
me Screen, page 17.
Identify the selected
format
The current format is highlighted in the bottom row of the AP25 display.
Mute the AP25 Touch the MUTE button. If successful, the MUTE button will change to
“MUTED” and its background color will change to red. See Adjusting the
F
ader, page 18.
Unmute the AP25 Touch the red MUTED button. If successful, the button will change to
“MUTE” and its background color will be gray.
View monitor settings Touch the MONITOR button. The Monitor window will display. It will
automatically disappear after 30 seconds. See Booth Monitor Volume,
pag
e 19.
Select monitor
channel(s)
Touch the MONITOR button. The Monitor window will display. Then
touch the MIX button and select the channel(s) you want to hear in the
monitor. When finished, touch the CLOSE button. See Booth Monitor
Volume, pag
e 19.
Change monitor volume Touch the MONITOR button. The Monitor window will display. Then
touch the + or – button until the desired volume is set. The window will
automatically disappear after 30 seconds. See Booth Monitor Volume,
pag
e 19
Mute the monitor Touch the MONITOR button. The Monitor window will display. Then
touch the MUTE button in the monitor window. The MUTE button will turn
red. Note that the Monitor button to the left of the window also turns red
to indicate a muted state. The window will automatically disappear after
30 seconds.
Unmute the monitor Touch the MONITOR button. The Monitor window will display. Then
touch the MUTE button in the monitor window. The MUTE button will turn
from red to gray. Note that the Monitor button to the left of the window
also turns gray to indicate the unmuted state. The window will
automatically disappear after 30 seconds
