Appendix D: AP25 Product Specifications D-2 Document #: 9301H79500 Ver. 1.00
Signal Outputs
Digital Audio Outputs
Channels: 16, fully routable as to input
Connectors: Two DB25 Male (Ch1-8 and 9-16)
Digital Format: AES/EBU
Sample Rates: 48kHz, 96 kHz and 192kHz
Analog Audio Outputs
Channels: 16 (fully routable as to input), common mapping with Digital Outputs
Balanced (can be connected unbalanced or single ended)
Connectors: Two DB25 Male (Ch1-8 and Ch9-16)
Level: 300mV with Fader at 7, +26dBu max (balanced)
Connector: 1 single ended RCA output, channel-selectable to drive an external monitor.
Adjustable Levels, to 300mV RMS
Connector: 1 single ended RCA output, summed output for the hearing impaired. - Fixed Level
Out, 300mV RMS
Audio EQ
Dirac Live® Room Optimization (option)
16-Channel Dirac Live® room optimization
Installer kit required to install Dirac Live®
3rd Octave EQ
16 channels - 31 user-adjustable bandpass filters
Gain +/-6dB adjustable in 0.5dB steps
Frequencies range from 20Hz to 20kHz.
Parametric
16 channels with 3 user-adjustable parametric filters for shaping Subwoofer response.
Adjustable from 20 to 200Hz, gain +/-6dB in 0.1dB steps
Q range from 0.7 to 5.
Hi/Low Active Crossovers
Adjustable from 20Hz to 20kHz; adjustable slope of 6, 12, 18 or 24dB per octave (Linkwitz-Riley,
Butterworth or Bessel)
Bass/Treble tone control
Adjustable +/-6dB at 150Hz and 5.5kHz
Corner frequency for bass adjustable from 50Hz to 300Hz
Corner frequency for treble adjustable from 1.5kHz to 12.0kHz
