AP25 Installation and Operating Guide Page 68
AP25 Installation & Operating Guide Document # 9301H79500 Ver. 1.00
Table 13. Input Source Mapping
INPUT OUTPUT
Analog 8 Channel Processor Channel 1 ¼ 8
NonSync1 L/R (set to Screen Channels) Processor Channel 1, 2 (L, R)
NonSync1 L/R (set to Surround
Channels)
Processor Channel 5, 6 (Ls, Rs)
NonSync1 L/R (set to Screen &
Surround Channels)
Processor Channel 1, 2, 5, 6 (L, R, Ls, Rs)
NonSync1 L/R (set to Matrix Decoder) Processor Channel 1, 2, 3, 5, 6 (L, R, C,
Ls, Rs)
MIC Pre (set to Screen Center) Processor Channel 3 (Center)
MIC Pre (set to Screen Channels) Processor Channel 1, 2 (L, R)
MIC Pre (set to Surround Channels) Processor Channel 5, 6 (Ls, Rs)
MIC Pre (set to Screen & Surround
Channels)
Processor Channel 1, 2, 5, 6 (L, R, Ls, Rs)
Optical (option, see appendix F) Processor Channel 1 ¼ 8
Digital Channel 1 ¼ 16 Processor Channel 1 ¼ 16
Digital Channel 1 ¼ 8 Processor Channel 1 ¼ 8
Digital Channel 9 ¼ 16 Processor Channel 1 ¼ 8
TosLink A Processor Channel 1 ¼ 2
1
TosLink B
Processor Channel 1 ¼ 2
1
S/PDIF Coax
Processor Channel 1 ¼ 2
1
HDMI Port 1-4
Maps to…
Processor Channel 1 ¼ 8
1
If a Dolby
®
Digital bitstream is detected and decoded, the decoded stream will be routed to the first
eight channels internally on the AP25. See section 4.3.6.6 Decoder Setup for more information.
