Issued: 24.02.2005
STRIDER MD
Tools required:
1 x Allen key (size 5 mm)
Loosen the Allen screw (4) and remove.➨
6.2.3 Adjusting the armrest height
The armrest height is adjusted using
four holes in the armrest support (b).
The height can be adjusted in stages
of 10 mm.
Pull the armrests upwards to the required
height until the hole in the armrest
support appears through the hole in the
seat tube (5).
Reinsert the Allen screw and tighten.
➨
➨
Loosening the fixing
Adjusting the armrest
height
Adjusting the seat position
