Issued: 24.02.2005

STRIDER MD

18.3.2 Wheels - removal and replacement - 3-wheel version

Secure the Strider against rolling away.

Lift the front end of the Strider and

support it (see chapter 19.0).

Hold the axle (1) with a ring spanner

(size 14 mm) and remove the self-

locking nut (2; size 17 mm).

Pull the axle out of the steering fork and

the wheel.

Remove the wheel and spacer bushes

from the steering fork.

➨

Tools required:

1 x ring spanner, size 14 mm

1 x ring spanner, size 17 mm

Removing the front wheel:

Front wheel

Removal and replacing the rear wheel:

Removing and replacing the rear wheel

must be carried out as described in the

chapter “Removing and replacing wheels -

4-wheel version“.

Replacing the front wheel:

Repairs - mechanics

Fitting the front wheel

Place the wheel and spacer bushes

(3 + 4) in the steering fork.

Push the axle (5) into the steering fork

and the wheel.

Screw the axle self-locking nut (6) and

tighten it (size 17 mm). While doing this,

prevent the axle from turning using a

second ring spanner (size 14 mm).

Lower the Strider.

➨
