Days Strider MD 4 - Wheels - removal and replacement - 4-wheel version

74
Issued: 24.02.2005
STRIDER MD
Push the wheel onto the stem (2) as far
as the wheel stop.
➨
18.3.3 Wheels - removal and replacement - 4-wheel version
Tools required:
1 x socket spanner, size 19 mm
Removing the wheels:
NOTE
• Do not use force to remove the
wheels from the axles.
Your specialist dealer has the
necessary special tools.
• The handbrake brake drum is
bolted to the front wheel on the
4-wheel Strider.
Fitting the front wheel:
Repairs - mechanics
Front wheel
Rear wheel
Fitting the front wheel
Screw the wheel fixing self-locking nut
(3) and tighten it (size 19 mm).
Lower the Strider.
Retighten the self-locking nut (3).
➨
➨
➨
Loosen the self-locking nut (1) for the
wheel fastening (size 19 mm).
Secure the Strider against rolling away.
Lift the Strider and support it
(see chapter 19.0).
Remove the self-locking nut for the
wheel fastening (size 19 mm).
Pull the wheel off the stem.
➨
➨
➨
➨
➨
