Days Strider MD 4 - Working step summary; Removing the seat; Removing the rear panelling

52
Issued: 24.02.2005
STRIDER MD
Tilt the seat backrest forwards.
Lift the seat while pulling the seat lock
(a) out of the seat support (1).
➨
➨
Pull the rear panelling off the Strider
upwards.
➨
Removing the seat
Removing the rear
panelling
In just a few steps you can dismantle the
Strider down to the following components to
make it ready for transport:
1. Chassis
2. Batteries
3. Drive unit
4. Rear panelling
5. Seat unit
1.Remove the seat unit.
2.Remove the rear panelling.
3.Remove the batteries.
4.Fold the tiller down.
5.Disengage the drive unit from the chassis.
Remove the rear panelling.➨
Transporting the Strider
14.3.1 Working step summary
14.3.2 Removing the seat
Press the locking device (A) on the
plug and disconnect the electric cable
connecting plug (1) to the rear lights
and rear indicators.
➨
14.3.3 Removing the rear panelling
