Days Strider MD 4 - Lighting - 4 wheel version; Replacing bulbs in headlights and rear light

79
Issued: 24.02.2005
STRIDER MD
Removing the lamp lens
(Example: rear light)
Repairs - lighting
Tools required:
1 x screwdriver; Phillips head No. 2
Bulb version used: 24 V / 5 Watt
(glass base lamp)
Loosen the fixing screw (1) and remove
the front or rear light lens.
➨
NOTE
The working sequence for front and
rear indicators is the same, and is
described using photographs of the
rear lights.
Removing the bulb
Fitting a new bulb
Insert the rear or front light lens and
secure with the fixing screws.
➨
18.5 Lighting - 4 wheel version
18.5.1 Replacing bulbs in headlights and rear light
(2.) Align the bulb base with the bulb
holder and press the bulb in.
➨
(1.) Pull the bulb out of the lamp holder.➨
