Days Strider MD 4 - Unlocking the drive unit; Tilt the drive unit away; Separating the chassis

54
Issued: 24.02.2005
STRIDER MD
Remove the frames (11) upwards from
the holding bolts (12) on the drive unit.
➨
Separating the chassis
Open the clamping bolt clamping lever
(9) and fold the clamping bolt upwards.
➨
Unlocking the drive unit
Tilt drive unit to the rear onto the anti tip
wheels (10).
➨
Tilt the drive unit away
Transporting the Strider
NOTE
Use rear bumper as grip to stowe
the drive unit.
