Days Strider MD 4 - Refitting battery cables

84
Issued: 24.02.2005
STRIDER MD
Fire and burn hazard if battery terminal is
short-circuited!
• Never touch both battery terminals simultaneously with
tools (shorting out).
• Terminals are protected with insulating caps. Only ever
remove the insulating cap from the terminal which you
are going to loosen.
Repairs - batteries
18.7.2 Refitting battery cables
Tools required:
2 x ring spanner; size 10 mm
Remove the batteries from the Strider as
described in chapter 14.3.4.
➨
First (1) loosen the terminal on the
battery negative terminal (black cable)
and remove the cable.
Then (2) loosen the terminal on the
battery positive terminal (red cable)
and remove the cable.
➨
➨
Refitting the battery cable:
Reinserting the batteries into the Strider
as described in chapter 14.4.3.
➨
Replacing the battery and connect the
battery cable in reverse order:
First connect the cable to the battery
positive terminal (2).
Then connect the cable to the battery
negative terminal (1).
➨
