DCS RGSC-305 - TROUBLESHOOTING AND WIRING; Common Operational Issues and Checks

PRELIMINARY
31
TROUBLESHOOTING
CONDITION CHECK
No Bake
No Broil
No Clean
Not Locking and Un-Locking
Burners Not Lighting
Cooking Complaints
 Bake igniter 3.0 amp to 3.3 amp draw ATC continuity
 Oven T-Stat contacts
 Main gas valve “OFF”
 Selector switch contacts 30 – 33:40 – 43
 Dual safety valve continuity
 Broil igniter 3.0 amp to 3.3 amp draw HTC continuity
 Oven T –Stat contacts
 Main gas valve “OFF”
 Selector switch contacts (3-31;30-34;56-36;57-37;40-42)
 Dual safety valve continuity
 See “Clean Relay Section”
 See motorized latch
 See above
 See motorized latch
 See “Clean Relay Section”
 Check supply voltage 120 VAC
 Check for spark at burner
 Igniter dirty
 Check igniter switches
 Check igniter module
 Check operating gas pressure
 See “Cooking Section”
