10. Specifications
10.1 Mechanical
Display Unit
Dimensions 13.33 cm x 3.68 cm x 2.79 cm
Weight 0.17 kg
Computer Unit
Dimensions 13.33 cm x 3.68 cm x 7.62 cm
Weight 0.45 kg
Hand-Held Remote
Dimensions 12.70 cm x 3.04 cm x 5.33 cm
Weight 0.26 kg
Ka-Band Silver Ring Antenna
Dimensions 9.77 cm x 5.33 cm
Weight 0.20 kg
K-Band Antenna
Dimensions 10.54 cm x 7.62 cm
Weight 0.37 kg
K-Band Directional Antenna
Dimensions 10.54 cm x 7.62 cm
Weight 0.37 kg
10.2 Antenna
K-Band
Nominal transmission frequency 24.150 GHz
Nominal horizontal beamwidth 12°
Polarization Circular
Nominal microwave power output 7mW
Maximum aperture power density < 1mW/cm
2
