Genesis II Select
™
User’s & Installation Manual
16/September/2015
54
K-Band Directional
Nominal transmission frequency 24.150 GHz
Nominal horizontal beamwidth 12º
Polarization Linear (Vertical)
Nominal microwave power output 5mW
Maximum aperture power density < 1mW/cm
2
Ka-Band Silver Ring
Nominal transmission frequency 35.500 GHz
Nominal horizontal beamwidth 12°
Polarization Circular
Nominal microwave power output 15mW
Maximum aperture power density < 2 mW/cm
2
10.3 Environment
Ambient operating temperatures -30°C to +70°C
Maximum humidity 90% relative humidity
at 37°C
10.4 Power Consumption
Supply voltage range 10.8 to 16.5VDC
with internal, resettable fuse
Low voltage threshold 10.8VDC
with visual indicator
Current draw with 13.6VDC applied in various modes:
Standby (antenna OFF) 0.60 amperes
Ant. ON, no targets displayed 0.85 amperes
Ant. ON, 55 target displayed 0.95 amperes
Ant. ON, 20 target, 35 patrol 1.00 amperes
Ant. OFF, segment check 888 888 888 1.05 amperes
Ant. ON, segment check 888 888 888 1.30 amperes
