Genesis II Select
™
User’s & Installation Manual
16/September/2015
31
5. Communication System Controls
You can congure the Genesis II Select™ through the serial
communications (COM) port on the rear panel to communicate
with PCs, speed signs, and in-car video systems, such as the Decatur
Electronics Responder 1000™ and the Decatur Electronics Vehicle
Interface Portal (VIP)™. The communications cable does not come
with your order and can be purchased separately from Decatur
Electronics or you authorized dealer. See Appendix A for the more
details on the serial communications port conguration.
6. Operating the Genesis II Select™
After you test and conrm that the unit is properly installed, it is
ready for use.
6.1 Power
The PWR button on the hand-held remote turns the Genesis II
Select™ on and o. After you press the PWR button, the display
illuminates and the computer checks the circuitry. If the power-up
checks pass, the computer displays TEST PASS in the MODE window.
If the power-up checks fail, a system error message (SYS) will display
in the MODE window and the unit will not respond to any control
except the PWR button to power down. Turn the unit o then back
on. If the error message persists, remove the unit from service and
contact Decatur Electronics or your authorized dealer.
t 8IFOUIF(FOFTJT**4FMFDUJTQPXFSFEEPXOJUTUPSFT
the current settings. These settings are restored the
next time you power up the unit.
6.2 Front and Rear Antenna
At power up, the Genesis II Select™ antennas are in standby mode.
(Standby mode is when the antenna is not transmitting.) If no
antenna is connected to the unit, the FRONT and REAR lights cycle on
BOEPòBOE"OU EJTQMBZTJOUIF.0%&XJOEPX
