9
BUTTONS AND CONNECTIONS
REMOTE CONTROL
1
2
5
6
8
9
10
3
4
7
11
12
13
1. Numerical Keypad: Buttons 1-8 displays the
corresponding camera on full screen.
0 disables / enables the mouse.
2. All: Switch to all camera viewing mode.
3. Menu: Access the main menu and exit the
current menu.
4. Select/Enter: Allows you to select options.
5. Directional Keys: Allow you to navigate through
the menu.
6. Audio/Search: Searches and nds any channels
that have an audio-supported
camera attached to it
(not included).
7. Mute: Mutes sound.
8. Rewind: Rewinds footage.
9. Record: Begins recording based on the 24
hour schedule.
10. Pause: Pauses playback footage and starts/
stops sequence mode.
11. Play: Calls up the playback menu.
12. Fast Forward: Fast forwards through playback
footage and allows you to navigate
the menu to the right.
13. Stop: Stops recording and/or
playback footage.
