12. ESS configuratiion
12.1 ESS nominal values
In the section “Power source data”, all AC values were collected. Now they can be entered into the ASC.
12.1.1 Nominal ratings
Use the values collected in the Power source data chapter to adjust the nominal rating parameter values.
Menu Function Comments
6002 Set the total power rating of the energy storage system.
6005 Set the Q rating of the inverter. If given, otherwise, set to the same value as 6006.
6006 Set the S rating of the inverter.
12.1.2 Nominal current
The voltage and current measurements need to be connected and set up in the menus.
COMMISSIONING GUIDELINES 4189341077D EN Page 33 of 58
